Some military aircraft pictures from my travels...

Discussion in 'Academy/Military News' started by scoutpilot, Sep 24, 2011.

  1. scoutpilot

    scoutpilot Member

    Joined:
    Apr 29, 2010
    Messages:
    4,276
    Likes Received:
    608
    Ran into a few of our multi-service brethren at various locales on my flight out west. These first two were in Amarillo, TX.

    F-18F Super Hornet. Unsure if it's a Squid or Jarhead version, as it wasn't marked and the crew was off being good aviators (eating lunch). My guess would be the latter, though.

    Behind is a USMC CV-22 Osprey. Loudest thing on the planet. Incidentally, the Bell Textron final assembly and test plant is at Amarillo, so there are always CV-22s in the pattern. This particular one was a fleet model, and the crew was waiting because it was broken.

    [​IMG]

    AH-1W Cobra. Bell also builds the Cobra and Huey line at Amarillo, so it's not rare for them to show up. Two old snakes rolled in while we were pre-flighting. You can see the tail of an Air Force T-38 Talon.
    [​IMG]

    This is in Fayetteville, AR. There was a military air show going on and Coast Guard HC-144 stopped in to do a static display. A rare sight indeed. It was the first time I've ever seen a USCG aircraft besides a Dauphin. There was plenty of other hardware there, both old and new.

    [​IMG]

    Keep your eyes open at regional airports. Military aircraft frequently stop in to refeul.

  2. Just_A_Mom

    Just_A_Mom Member

    Joined:
    Jul 9, 2006
    Messages:
    4,826
    Likes Received:
    2
    Cool pics!
    You might want to double check but I don't think that Marines fly the Super Hornet.

  3. USMA2016

    USMA2016 Appointee - Class of 2016

    Joined:
    Dec 19, 2010
    Messages:
    519
    Likes Received:
    0
    I live next to Marine Corps Air Station Miramar and those Ospreys and hornets are always flying overhead. It's really sick!

  4. scoutpilot

    scoutpilot Member

    Joined:
    Apr 29, 2010
    Messages:
    4,276
    Likes Received:
    608
    I thought it was odd that it was unmarked. I did notice one Marine strolling around with a test pilot patch. Perhaps something is afoot.

    The Cobra is a sexy old dog. That old underslung rotor turns so slowly. I took more pics, but can't post them.

  5. raimius

    raimius USAFA Alumnus

    Joined:
    Jun 9, 2006
    Messages:
    2,239
    Likes Received:
    273
    Did someone say underslung rotor?
    [​IMG]
    :biggrin:

  6. scoutpilot

    scoutpilot Member

    Joined:
    Apr 29, 2010
    Messages:
    4,276
    Likes Received:
    608
    Yes...the granddaddy of them all.

  7. hornetguy

    hornetguy USAFA Cadet

    Joined:
    Jun 9, 2006
    Messages:
    2,295
    Likes Received:
    129
    Ok, what does it mean to be "underslung?"

  8. scoutpilot

    scoutpilot Member

    Joined:
    Apr 29, 2010
    Messages:
    4,276
    Likes Received:
    608
    [​IMG]

    The rotorhead employs a teeter-totter type design. However, the gimbal hinge is located above the centerline of the long-axis of the blade. Thus, the blade rides below its point of attachment on the rotating main mast and is therefore said to be "underslung" relative to that point.

    If you know anything about rotary wing aerodynamics, you're likely aware that the blades must flap and feather as they rotate as a result of dissymmetry of lift throughout the rotor disc and the resultant change in induced flow. This flapping action requires that the blades lead and lag (speed up and flex forward or slow down and flex aft) relative to their mounting point to preserve their angular momentum. Flexing up and down moves the center-of-mass of the blade closer to the axis of rotation, and if you've ever seen a figure skater spin faster as she pulls her arms into her body, you know what happens when the blade center-of-mass moves inward.

    The underslung rotorhead elminates the need for lead-lag hinges and drag dampers by maintaining a constant distance between the COM of the blade and the mast.

    A picture is worth a thousand words...
    [​IMG]

    It's a simple design, but there's a lot of slop in it. It can't maneuver like an articulated or soft-in-plane rotor. Hence, the Z-model Cobra will not use the old design.

  9. AF6872

    AF6872 Member

    Joined:
    Mar 4, 2007
    Messages:
    2,868
    Likes Received:
    237
    When a "granddaddy" Is in the air nearby I always look up. Unmistakable sound from the "good old days".:wink:

  10. scoutpilot

    scoutpilot Member

    Joined:
    Apr 29, 2010
    Messages:
    4,276
    Likes Received:
    608
    Thanks. Every now and then I'm good for something.

    That top picture is actually a very simple rotorhead off the AH-1W. There's a reason the main nut that holds the yoke assembly to the mast is called the "Jesus Nut."

  11. Boozebin

    Boozebin Member

    Joined:
    Sep 23, 2010
    Messages:
    647
    Likes Received:
    313
    I wish I had this knowledge before I went to the Air show this weekend on Fort Carson’s Butts Field! I would have been staring at the blades wondering if that what Scout was talking about.

  12. AF6872

    AF6872 Member

    Joined:
    Mar 4, 2007
    Messages:
    2,868
    Likes Received:
    237
    If you wondered and thought about how it worked and stayed in the air you wouldn't board it. If it got you from point A to B it worked. They weren't contraptions but then again you had other things to think about while you were in the slings. They were a workhorse with a good airworthy history. Some Sikorsky Guys were having lunch today down the street from our local airfield. As there were only three I think it was a Blackhawk. One Green flight suit and two Brown suits?

  13. scoutpilot

    scoutpilot Member

    Joined:
    Apr 29, 2010
    Messages:
    4,276
    Likes Received:
    608
    Hard to say for sure, but the most common Sikorsky hardware DoD uses is the dash60 series, so it's likely.

  14. AF6872

    AF6872 Member

    Joined:
    Mar 4, 2007
    Messages:
    2,868
    Likes Received:
    237
    But the "Huey" does have a distictive sound. If you hear it overhead it sounds like it is comming into a landing area or an LZ and you will never forget that sound. Hear them overhead and it does perk up your ears

  15. scoutpilot

    scoutpilot Member

    Joined:
    Apr 29, 2010
    Messages:
    4,276
    Likes Received:
    608
    Indeed. Long blades with a wide chord give that sound, which is common to early models of Hueys and Cobras.

  16. AF6872

    AF6872 Member

    Joined:
    Mar 4, 2007
    Messages:
    2,868
    Likes Received:
    237
    Can never forget that sound of a Huey comming in or overhead.:thumb:

  17. scoutpilot

    scoutpilot Member

    Joined:
    Apr 29, 2010
    Messages:
    4,276
    Likes Received:
    608
    My first IP in flight school still had his Huey initial pitch-pull muscle memory for autorotations. He couldn't shake it, so we'd sail down the runway forever before we bled off the rotor.

  18. AF6872

    AF6872 Member

    Joined:
    Mar 4, 2007
    Messages:
    2,868
    Likes Received:
    237
    On the PAD: Huey Command Pilot asks if anyone has never ridden in a helicopter before. Second LT says "never" (before we could shut him up). Buckle up. The most amazing low level lift off and down the road through the jungle you have ever experienced.

    Didn't know the Huey could autorotate but I guess all can unless severely damaged. Used to watch the PEDRO's HH-43 do autorotate as practice. Then saw them do the real thing with full motor to blow the fire out as crash rescue saved the pilot.

  19. hornetguy

    hornetguy USAFA Cadet

    Joined:
    Jun 9, 2006
    Messages:
    2,295
    Likes Received:
    129
    I might have to tell helo pilots every time I haven't flown in one before from now on. :)

    I've been on a helo twice: once around the great barrier reef, once on a UH-1 to tour Tokyo a la Yokota AFB. :)

  20. AF6872

    AF6872 Member

    Joined:
    Mar 4, 2007
    Messages:
    2,868
    Likes Received:
    237
    If you have to go only twice those sound like some great flights.:thumb:
